Most EVPN documentation rushes into the complexities of symmetric IRB, type-5 EVPN routes, and EVPN IP-VRFs, but if you want to master a technology, it’s better to take it slow and proceed with small steps. In today’s lab exercise, we’ll do just that: explore what happens when you add IP addresses (we’ll use anycast gateways) to VLAN interfaces tied to EVPN MAC-VRF instances.

You can run the lab on your own netlab-enabled infrastructure (more details), but also within a free GitHub Codespace or even on your Apple-silicon Mac (installation, using Arista cEOS container, using VXLAN/EVPN labs).

Most vendors “discovered” anycast gateways when they tried implementing routing between MAC-VRFs in an EVPN environment and hit all the usual tripwires (more about that later). A few exceptions (like Arista) supported them on VLAN segments for over a decade, and it was a no-brainer to extend that support to VXLAN segments.

Want to try out how that works? The Anycast Gateways on VXLAN Segments lab exercise is just what you need.

In the first EVPN/VXLAN lab, we added the EVPN control plane to bridging over VXLAN. Now, let’s try out a more complex scenario: several EVPN MAC-VRFs mapped to different VLAN segments on individual PE-devices.

You can run the lab on your own netlab-enabled infrastructure (more details), but also within a free GitHub Codespace or even on your Apple-silicon Mac (installation, using Arista cEOS container, using VXLAN/EVPN labs).

In the previous EVPN/VXLAN lab exercises, we covered the basics of Ethernet bridging over VXLAN and the use of the EVPN control plane to build layer-2 segments.

It’s time to move up the protocol stack. Let’s see how you can route between VXLAN segments, this time using unique unicast IP addresses on the layer-3 switches.

You can run the lab on your own netlab-enabled infrastructure (more details), but also within a free GitHub Codespace or even on your Apple-silicon Mac (installation, using Arista cEOS container, using VXLAN/EVPN labs).

In the previous VXLAN labs, we covered the basics of Ethernet bridging over VXLAN and a more complex scenario with multiple VLANs.

Now let’s add the EVPN control plane into the mix. The data plane (VLANs mapped into VXLAN-over-IPv4) will remain unchanged, but we’ll use EVPN (a BGP address family) to build the ingress replication lists and MAC-to-VTEP mappings.

In the first VXLAN lab, we covered the very basics. Now it’s time for a few essential concepts (before introducing the EVPN control plane or integrated routing and bridging):

• Each VXLAN segment could have a different set of VTEPs (used to build the BUM flooding list)
• While the VXLAN Network Identifier (VNI) must be unique across the participating VTEPs, you could map different VLAN IDs into a single VNI (allowing you to merge two VLAN segments over VXLAN)
• Neither VXLAN VNI nor VLAN ID has to be globally unique (but it helps to make them unique to remain sane)

After launching the BGP labs in 2023 and IS-IS labs in 2024, it was time to start another project that was quietly sitting on the back burner for ages: open-source (and free) VXLAN/EVPN labs.

The first lab exercise is already online and expects you to extend a single VLAN segment across an IP underlay network using VXLAN encapsulation with static ingress replication.

In the multi-pod EVPN design, I described a simple way to merge two EVPN fabrics into a single end-to-end fabric. Here are a few highlights of that design:

• Each fabric is running OSPF and IBGP, with core (spine) devices being route reflectors
• There’s an EBGP session between the WAN edge routers (sometimes called border leaf switches)
• Every BGP session carries IPv4 (underlay) and EVPN (overlay) routes.

In that design, the WAN edge routers have to support EVPN (at least in the control plane) and carry all EVPN routes for both fabrics. Today, we’ll change the design to use simpler WAN edge routers that support only IP forwarding.

In the EVPN Designs: Layer-3 Inter-AS Option A, I described the simplest multi-site design in which the WAN edge routers exchange IP routes in individual VRFs, resulting in two isolated layer-2 fabrics connected with a layer-3 link.

Today, let’s explore a design that will excite the True Believers in end-to-end layer-2 networks: two EVPN fabrics connected with an EBGP session to form a unified, larger EVPN fabric. We’ll use the same “physical” topology as the previous example; the only modification is that the WA-WB link is now part of the underlay IP network.

A netlab user wanted to explore a multi-site design where every site runs an independent EVPN fabric, and the inter-site link is either a layer-2 or a layer-3 interconnect (DCI). Let’s start with the easiest scenario: a layer-3 DCI with a separate (virtual) link for every tenant (in the MPLS/VPN world, we’d call that Inter-AS Option A)
